A. R1:
- Routes advertised to ISP-1: 0x AS-path prepend
- Routes received from ISP-1: HIGH local-preference
- Routes advertised to R2: no action
- Routes received from R2: community NO-EXPORT
R2:
- Routes advertised to ISP-2:5x AS-path prepend
- Routes received from ISP-2: LOW local-preference
- Routes advertised to R1: community NO-ADVERTISE
- Routes received from R1: no action
B. R1:
- Routes advertised to ISP-1: 0x AS-path prepend
- Routes received from ISP-1: HIGH local-preference
- Routes advertised to R2: community NO-EXPORT
- Routes received from R2: no action
R2:
- Routes advertised to ISP-2: 5x AS-path prepend
- Routes received from ISP-2: LOW local-preference
- Routes advertised to R1: no action
- Routes received from R1: no action
C. R1:
- Routes advertised to ISP-1: 0x AS-path prepend
- Routes received from ISP-1: LOW local-preference
- Routes advertised to R2: community NO-ADVERTISE
- Routes received from R2: no action
R2:
- Routes advertised to ISP-2: 5x AS-path prepend
- Routes received from ISP-2: HIGH local-preference
- Routes advertised to R1: no action
- Routes received from R1: community NO-ADVERTISE
D. R1:
- Routes advertised to ISP-1: 5x AS-path prepend
- Routes received from ISP-1: LOW local-preference
- Routes advertised to R2: community NO-ADVERTISE
- Routes received from R2: no action
R2:
- Routes advertised to ISP-2: 0x AS-path prepend
- Routes received from ISP-2: HIGH local-preference
- Routes advertised to R1: community NO-EXPORT
- Routes received from R1: no action
