Pass the Fortinet Network Security Expert NSE8_812 Questions and answers with ValidTests

SD-WAN is a feature that allows users to optimize network performance and reliability by using multiple WAN links and applying rules based on various criteria, such as latency, jitter, packet loss, etc. One way to ensure that the FortiGate DNS resolution times are as low as possible with the least amount of work is to configure local out traffic to use the outgoing interface based on SD-WAN rules with the interface IP and configure an SD-WAN rule to the DNS server. This means that the FortiGate will use the best WAN link available to send DNS queries to the DNS server according to the SD-WAN rule, and use its own interface IP as the source address. This avoids NAT issues and ensures optimal DNS performance. References: https://docs.fortinet.com/document/fortigate/7.0.0/sd-wan/19662/sd-wan

A is correct because the error message "The CRL is not accessible" indicates that the root FortiGate cannot access the CRL for the FortiClient EMS server. Verifying that the CRL is accessible will fix this error.

D is correct because the error message "The FortiClient EMS server is not authorized" indicates that the root FortiGate is not authorized to connect to the FortiClient EMS server. Authorizing the root FortiGate on the FortiClient EMS server will fix this error.

The other options are incorrect. Option B is incorrect because exporting and importing the FortiClient EMS server certificate to the root FortiGate will not fix the CRL error. Option C is incorrect because installing a new known CA on the Win2K16-EMS server will not fix the authorization error.

References:

Troubleshooting FortiClient EMS connectivity | FortiClient / FortiOS 7.0.0 - Fortinet Document Library

Authorizing FortiGates with FortiClient EMS | FortiClient / FortiOS 6.4.8 - Fortinet Document Library

https://docs.fortinet.com/document/fortigate/7.0.0/administration-guide/185333/forticlient-ems%E2%80%9D

To retrieve an SSO group called SalesGroup using the FortiAuthenticator REST API, the following issues need to be fixed in the API call:

The API version should be v2, not v1, as SSO groups are only supported in version 2 of the REST API.

The HTTP method should be GET, not POST, as GET is used to retrieve information from the server, while POST is used to create or update information on the server. Therefore, a correct API call would look like this: curl -X GET -H “Authorization: Bearer ” https://fac.example.com/api/v2/sso/groups/SalesGroup References: https://docs.fortinet.com/document/fortiauthenticator/6.4.1/rest-api-solution-guide/927310/introduction https://docs.fortinet.com/document/fortiauthenticator/6.4.1/rest-api-solution-guide/927311/sso-groups

A. Systems running on Azure will need to go through the main data center to access the services on Oracle Cloud. This is because the Oracle Cloud is not directly connected to the Azure Cloud. The traffic will need to go through the main data center in order to reach the Oracle Cloud.

C. Branch FortiGate devices must be configured as VPN clients for the branches' internal network to be able to access Oracle services without using public IPs. This is because the Oracle Cloud does not allow direct connections from the internet. The traffic will need to go through the FortiGate devices in order to reach the Oracle Cloud.

The other options are not correct.

B. Use FortiGate VM for IPSEC over ExpressRoute, as traffic is not encrypted by Azure. This is not necessary. Azure does encrypt traffic over ExpressRoute.

D. Two ExpressRoute services to the main data center are required to implement SD-WAN between a FortiGate VM in Azure and a FortiGate device at the data center edge. This is not necessary. A single ExpressRoute service can be used to implement SD-WAN between a FortiGate VM in Azure and a FortiGate device at the data center edge.

https://learn.microsoft.com/en-us/azure/expressroute/expressroute-about-encryption
